Grade 12 Maths · Analytical Geometry

Use the equation of a circle

Use the circle equation (x − a)² + (y − b)² = r², for example centre (2; −1), radius 3 gives (x − 2)² + (y + 1)² = 9.

past paper questions use it: 7 past paper questions use it
videos: 3 videos

Learn it: use the equation of a circle

Pick one and watch it, then try the questions below. Videos load only when you tap play.

Equation of Circle Grade 12Kevinmathscience

Complete Square Grade 12 Analytical GeometryKevinmathscience

Analytical Geometry Grade 12: L3 Convert equation of circle to centre- radius formOnline Maths by Miss Pythagoras

Now try it on a real exam question

No sign-up. Takes 3 minutes.

Question 4.6 · May/June 2025 · Paper 2 · National (DBE) · 3 marks

In the diagram, M is the centre of the circle having equation

(x - 3)^{2} + y^{2} = 25

E (- 1; 3)

and T are points on the circle.

EC is a tangent to the circle at E and cuts the x-axis at D.

E D = \frac{15}{4}

units. MT is produced to meet the tangent at

C (- 7; p)

4.6 If the radius of the circle, centred at M, is increased by

7

units, determine whether S lies inside or outside the new circle. Support your answer with the necessary calculations.(3)

Work it out on paper first. Then mark yourself with the official memo, one tick at a time.

More past paper questions: use the equation of a circle

Work each one out first, then open the memo and check every tick.

3. Question WE11 · Siyavula Grade 12 Mathematics, 7.2 Equation of a circle, Worked example 11 · 5 marks
WE11 A circle with centre on the line $y = - x + 5$ passes through the points $P (5; 8)$ and $Q (9; 4)$ . Determine the equation of the circle.(5)
Show the memo (5 ticks)Memo
1. ✓
  General equation with centre on the line $(x - a)^{2} + (y - b)^{2} = r^{2}$
  The centre lies on $y = - x + 5$ , so it is $(a; - a + 5)$ :
  $(x - a)^{2} + (y + a - 5)^{2} = r^{2}$
  1 mark · Use the equation of a circle
2. ✓
  Substitute P $(5 - a)^{2} + (8 + a - 5)^{2} = r^{2}$
  $25 - 10 a + a^{2} + a^{2} + 6 a + 9 = r^{2}$
  $2 a^{2} - 4 a + 34 = r^{2} \dots (1)$
  1 mark · Use the equation of a circle
3. ✓
  Substitute Q $(9 - a)^{2} + (4 + a - 5)^{2} = r^{2}$
  $81 - 18 a + a^{2} + a^{2} - 2 a + 1 = r^{2}$
  $2 a^{2} - 20 a + 82 = r^{2} \dots (2)$
  1 mark · Use the equation of a circle
4. ✓
  Solve for a $(1) - (2)$ : $16 a - 48 = 0$
  $∴ a = 3$
  1 mark · Solve simultaneous equations by elimination
5. ✓
  Equation $r^{2} = 2 (3)^{2} - 20 (3) + 82 = 40$
  $b = - a + 5 = 2$
  The equation of the circle is $(x - 3)^{2} + (y - 2)^{2} = 40$ .
  1 mark · Use the equation of a circle
4. Question WE8 · Siyavula Grade 12 Mathematics, 7.2 Equation of a circle, Worked example 8 · 4 marks
WE8 Determine the coordinates of the centre of the circle and the length of the radius for $3 x^{2} + 6 x + 3 y^{2} - 12 y - 33 = 0$ .(4)
Show the memo (4 ticks)Memo
1. ✓
  Coefficients equal to 1Take out $3$ as a common factor:
  $x^{2} + 2 x + y^{2} - 4 y - 11 = 0$
  1 mark · Complete the square
2. ✓
  Complete the square $(\frac{2}{2})^{2} = 1$ and $(\frac{- 4}{2})^{2} = 4$
  $(x^{2} + 2 x + 1) - 1 + (y^{2} - 4 y + 4) - 4 - 11 = 0$
  $(x + 1)^{2} + (y - 2)^{2} = 16$
  1 mark · Complete the square
3. ✓
  CentreThe centre of the circle is $(- 1; 2)$ .
  1 mark · Use the equation of a circle
4. ✓
  Radius $r^{2} = 16$ , so the radius is $4$ units.
  1 mark · Use the equation of a circle
5. Question WE6 · Siyavula Grade 12 Mathematics, 7.2 Equation of a circle, Worked example 6 · 3 marks
WE6 Given a circle with centre $O (0; 0)$ and a radius of $45$ units. Determine the possible coordinates of the point(s) on the circle which have an $x$ -value that is twice the $y$ -value.(3)
Show the memo (3 ticks)Memo
1. ✓
  Equation of the circle $x^{2} + y^{2} = r^{2}$
  $x^{2} + y^{2} = (45)^{2}$
  $x^{2} + y^{2} = 45$
  1 mark · Use the equation of a circle
2. ✓
  Substitute x = 2y $(2 y)^{2} + y^{2} = 45$
  $5 y^{2} = 45$
  $y^{2} = 9$
  $∴ y = \pm 3$
  1 mark · Solve linear and non-linear simultaneous equations
3. ✓
  PointsIf $y = - 3$ : $x = 2 (- 3) = - 6$
  If $y = 3$ : $x = 2 (3) = 6$
  The points are $(6; 3)$ and $(- 6; - 3)$ .
  1 mark · Solve linear and non-linear simultaneous equations
